With maximum pressure for Hydrogen storage
The world has ideas on how the energy transition might work, BHDT provides the solutions.
For a number of years and with regard to mobility, battery-powered electric vehicles have been competing with solutions that have hydrogen-powered electric or combustion engines. The advantage of hydrogen-powered vehicles is that the achievable distances are much higher, very expensive, heavy batteries can be avoided by utilizing them, raw materials for the manufacture of the batteries only have to be used in very limited quantities and that there is no need for any time-consuming recycling of the batteries. The construction of hydrogen-powered vehicles, regardless of whether with a fuel cell or internal combustion engine, is comparatively simple and the vehicles can be refuelled using a concept similar to the filling station system for conventional internal combustion engines.
This poses special challenges for hydrogen tanks. In order to be able to store hydrogen in large quantities, it has to be heavily compressed, which is why containers are exposed to high internal pressure. Moreover, the containers must be made of very high-strength materials with an impermeable inner coating or lining to prevent the diffusion of hydrogen from the container and any hydrogen embrittlement of the material. A further challenge is presented by sealing concepts with the highest level of tightness at temperatures ranging from -50° C to 90° C. Operation at extremely low temperatures requires the use of very ductile materials and meticulous design of the containers in terms of fracture mechanics to prevent them from bursting, ruling it out in any case.
BHDT is currently exploring an innovative stationary tank system that is used at significantly higher internal pressures than conventional hydrogen tanks and can therefore store significantly more hydrogen in the same tank volume. Despite the enormous fatigue stress of such a system, these containers have a longer lifespan than containers currently available on the market. This development is not limited to the tanks; it is extended to pipes and valves in the same pressure class, allowing us to be able to support our customers holistically.
Design, calculation, production and testing of high-pressure components, which all adhere to international standards and specifications is BHDT’s core business. In accordance with ISO 9001, ISO 14001, ASME BPVC and API Q1, the company’s quality and environmental management systems have been certified by various third parties.
Decades of experience in the field of high-pressure technology, the selection of the appropriate materials, along with accurate order management are the preconditions for a high degree of reliability and the functionality of our products in compliance with international standards and our customers’ requirements.
Building upon our roots and gathering on more than 60 years of experience, BHDT is now the market leader for high pressure systems and valves in applications up to 3500 bar for LDPE/EVA and UREA plants.
Today, BHDT is in a position to deliver custom made connectors, prefabricated piping spools and special valves to our customers in the energy sector.
Contact Us
BHDT GmbH
Werk-VI-Straße 52
A-8605 Kapfenberg
Austria
Reception desk:
+43 3862 303-0
Sales and Order Management:
Head of Sales and Order Management:
Mr. Michael Simml +43 3862 303-270
Sales Manager:
Mr. Robert Eckl +43 3862 303-264
Sales Manager:
Mr. Thomas Richter +43 3862 303-202
High Pressure Storage Units
In order to store high pressure media, BHDT has developed categorized high pressure storage units that can be supplied in various sizes and for different pressure ranges.
Main Features:
- Operating Pressure: 150 – 3000 [bar g]
- Design Temperature: -50 to 150 [°C]
- Visual Instrumentation: Gauges
- Monitoring Instrumentation: Electrical transmitters deliver a 4-20 [mA] signal in various protocols
- Design Codes: ASME Sect. VIII Div. 1 (incl. U stamp), DIN / PED (incl. CE Marking), GOST, CML
Check Valves
Decades of experience and the supply of highly reliable valves has made BHDT well known all over the world as a manufacturer of high pressure valves, especially for urea, ammonia, melamine, LDPE and power plants.
BHDT offers a wide range of types: from standard to tailor-made check valves, both angled and globe.
All of the valves are designed to fully meet the clients’ requirements. Different face-to-face dimensions, connecting details, flow directions, internals (hollow cones, plate type, etc.) and options (steam jacket, flushing possibility, etc.) can be realised. BHDT Check Valves are designed to guarantee a reduced energy loss, due to the internal special design that minimizes fluid pressure drop. They are furthermore designed for different media applications and different installation orientations.
All of the valves undergo comprehensive testing procedures that guarantee the highest level of quality in the finished product. Other client or project-specific inspection requirements can be added during the ordering stage using a project-specific Inspection and Test Plan.
Main Features:
- Nominal size: ½”-10” (for urea, ammonia and melamine applications)
- Nominal pressure range PN325 (for urea, ammonia and melamine applications)
- Nominal size: DN3-DN89 or larger (for LDPE applications)
- Nominal pressure range PN500-PN4000 (for LDPE applications)
- Valves are exclusively made out of forged materials.
- Exchangeable seats, steam jackets, locking devices and many other features are available as per customer specifications.
- No copper or copper alloys are used for our valves.
- Connections can be produced to conform with all the international standards, such as ANSI B 16.5, 1500# to 2500#, DIN standard, IG (a BHDT standard, but also with customer standards such as Stamicarbon, Saipem, Urea Casale, Toyo, KBR, LYB, EXXON, DOW).
Actuated Control Valves
Decades of experience and the supply of the most reliable valves has made BHDT well known all over the world as a manufacturer of high pressure valves, especially for urea, ammonia, melamine, LDPE and power plants.
BHDT offers a wide range of types: from standard to tailor-made control valves, both angled and globe.
All of the valves are designed to fully meet the clients’ requirements. Different face-to-face dimensions, connecting details, flow directions and internals (exchangeable vs. firm seat), as well as heating and cooling jackets can be realised. BHDT Valves can be equipped with various types of actuators from different manufacturers (pneumatic, hydraulic, electric, etc.) and with accessories such as positioners, solenoid valves, position transducers and limit switches.
All BHDT Control Valve characteristics (equal, true linear and modified characteristics) are designed as per our customers’ requirements, process conditions and according to BHDT internal calculations. BHDT Control Valves can also be supplied with a multistage CV trim (Christmas tree design) which is calculated and designed to meet the most stringent customer requirements.
All of the valves undergo comprehensive testing procedures that guarantee the highest level of quality in the finished product. Other client or project-specific inspection requirements can be added during the ordering stage using a project-specific Inspection and Test Plan.
Main Features:
- Nominal size: ½”-16” (for urea, ammonia and melamine applications)
- Nominal pressure range PN325 (for urea, ammonia and melamine applications)
- Nominal size: DN3-DN89 or larger (for LDPE applications)
- Nominal pressure range PN500-PN4000 (for LDPE applications)
- Valves are exclusively made out of forged materials.
- Exchangeable seats, steam jackets, locking devices and many other features are available as per customer specifications.
- No copper or copper alloys are used for our valves.
- All connections can be produced to conform with all the international standards, such as ANSI B 16.5, 1500# to 2500 #, DIN standard, IG (a BHDT standard, but also with customer standards such as Stamicarbon, Saipem, Urea Casale, Toyo, KBR, LYB, EXXON, DOW).
- Various types of actuators (pneumatic, hydraulic, electric, etc.) from different manufacturers can be supplied with BHDT Actuated Control Valves.
- Controller: Hydraulic-Servovalve; Pneumatic-Positioner
- Feedback: Hydraulic-LVDT
- Control signals: Different signals possible
Manual On/Off Valves
Decades of experience and the supply of the most reliable valves has made BHDT well known all over the world as a manufacturer of high pressure valves, especially for urea, ammonia, melamine LDPE and power plants.
BHDT offers a wide range of types: from standard to tailor-made manual on/off valves, both angled and globe.
All of the valves are designed to fully meet the clients’ requirements. Different face-to-face dimensions, connecting details, flow directions and internals (exchangeable vs. firm seat), as well as heating and cooling jackets can be realised.
All of the valves undergo comprehensive testing procedures that guarantee the highest level of quality in the finished product. Other client or project-specific inspection requirements can be added during the ordering stage using a project-specific Inspection and Test Plan.
Main Features:
- Nominal size: ½”-12” (for urea, ammonia and melamine applications)
- Nominal pressure range PN325 (for urea, ammonia and melamine applications)
- Nominal size: DN3-DN89 or larger (for LDPE applications)
- Nominal pressure range PN500-PN4000 (for LDPE applications)
- Valves are exclusively made out of forged materials.
- Exchangeable seats, steam jackets, locking devices and many other features are available as per customer specifications.
- No copper or copper alloys are used for our valves.
- All connections can be produced to conform with all the international standards, such as ANSI B 16.5, 1500# to 2500 #, DIN standard, IG (a BHDT standard, but also with customer standards such as Stamicarbon, Saipem, Urea Casale, Toyo, KBR, LYB, EXXON, DOW).
- Manual operation (valves come equipped with gear operators from sizes 3″ and above as a standard).
